Click to Download literature mg-12cp.pdf

Click to see the Pin together Erection of the MG-12CP Presentation-2.pdf

MG-12Cp Paving Plant

Click to Download literature mg-11c.pdf

Click to Download literature mg-11c.pdf

We offer many types of stationary and mobile batching plants and accessories to go with each.

Description

Dual Mixer Paving Plant

The ERIE MG-12CP2 is the premier Dual Mixer Plant offered in the market today. State-of-the Art components have been combined with the most current innovations in batch plant design to set a new standard for super high speed, high production concrete paving. Mainline highway and airport paving projects that require sustained, high production concrete pours are no match for the MG-12CP2.

Features:

  • 720 CU YD/HR Production
  • (2) 12 cubic yard mobile tilt mixers
  • AR-400 hi-profile paving blades
  • 50 cubic yard mobile aggregate bin
  • 3 individual aggregate batchers
  • 48" batch transfer conveyor
  • 12 cubic yard cement batcher
  • 4 yard flyash batcher
  • 715 bbl mobile 2-compartment cement silo
  • Internal dust duct system
  • 4000 gallon water storage tank
  • 20 HP constant run water pump
  • 4" Badger electronic water meter with 2 stage feed
  • (2) 25 HP Ingersoll-Rand air compressors
  • ERIE Sentry computer control system​

A high degree of mobility and versatility exists throughout this family of Plants. Standard components insures flexibility in design and manufacturing. Erie's Strayer Plants are the standard in the industry

ABOUT THE PLANTS

Description

The MG-11C consists of separate aggregate, cement, and central mixer travel units. The mixer unit can be transported on a drop center trailer or can be trailorized for towing. Each travel unit comes completely assembled, which makes for fast erection time.

Features:
  • Up to 400 cubic yards per hour
  • 20,50,80,100,150, or 200 cubic yard aggregate bin
  • 10 or 12 cubic yard batching system
  • 36"or 48" wide batch transfer conveyor
  • 2000 cubic foot (500bbl.)
  • 2866 cubic foot (715bbl)
  • 3732 cubic foot (935bbl.)
  • 4598 cubic foot (1150bbl.)
  • Cement silos available in one or two compartment(s)
  • 3" or 4" water meter,with a 120 gallon water tank
  • 15 H.P. air compressor, with 120 gallon tank
  • 10 or 12 yard Erie Tilt Mixer​

MG-12Cp2 Paving Plant

Description

The MG-11C consists of separate aggregate, cement, and central mixer travel units. The mixer unit can be transported on a drop center trailer or can be trailorized for towing. Each travel unit comes completely assembled, which makes for fast erection time.

Features:
  • Up to 400 cubic yards per hour
  • 20,50,80,100,150, or 200 cubic yard aggregate bin
  • 10 or 12 cubic yard batching system
  • 36"or 48" wide batch transfer conveyor
  • 2000 cubic foot (500bbl.)
  • 2866 cubic foot (715bbl)
  • 3732 cubic foot (935bbl.)
  • 4598 cubic foot (1150bbl.)
  • Cement silos available in one or two compartment(s)
  • 3" or 4" water meter,with a 120 gallon water tank
  • 15 H.P. air compressor, with 120 gallon tank
  • 10 or 12 yard Erie Tilt Mixer​

REMCON ASSOCIATES, LLC

Click to Download literature mg-12cp2.pdf

Erie Strayer overs a wide selection of very versatile paving plants from self-erecting units to highly mobile single and twin mixer high production plants.

erie strayer paving plants

Description

The ERIE MG-12CP is the premier Single Mixer Plant offered in the market today. State-of-the Art components have been combined with the most current innovations in batch plant design to set a new standard for high speed, high production concrete paving. Unparalleled performance and reliability are trademarks that set the MG-12CP apart from the competition.

Features:
  • 12 cubic yard mobile tilt mixer
  • AR-400 hi-profile paving blades
  • 50 cubic yard mobile aggregate bin
  • 3 individual aggregate batchers
  • 48" batch transfer conveyor
  • 12 cubic yard cement batcher
  • 715 bbl mobile 2-compartment cement silo
  • Internal dust duct system
  • 4000 gallon water storage tank
  • 15 HP constant run water pump
  • 4" Badger electronic water meter with 2 stage feed
  • ERIE Sentry computer control system​​​

A high degree of mobility and versatility exists throughout this family of Plants. Standard components insures flexibility in design and manufacturing. Erie's Strayer Plants are the standard in the industry

MC-11C Paving Plant

MG-11C Paving Plant
